Description

Design standard:API 6D, API 608, BS 5351, ISO 17292
All the Metal seated ball valves supplied by SSIE are shut-off design to be applied for some poor service like high temperature, abrasive medium to solve the problem of inner leakage and outer leakage, and ensure reliable sealing with zero leakage

Product range:

• 1. Pressure range:CLASS 150Lb~2500Lb.

• 2. Nominal diameter:NPS 1/2”~60″.

• 3. Body material：Carbon steel, Stainless steel, Duplex, Alloy steel and special material.

• 4. End connection:RF, RTJ, BW, Hub.

• 5. Type of operation:Lever, Gear box, Electric, Pneumatic, hydraulic, Pneumatic-hydraulic device.

Product features:

• 1. Full bore or reduced bore.

• 2. Side entry, Top entry.

• 3. Advanced rocket-spraying process.

• 4. Optional locking device.

• 5. Optional stem extension.

• 6. Optional ISO 5211 top flange.

• 7. Optional seat function: DBB, DIB-1, DIB-2.
